• Country
• United States of America (USA)

• Manufacturer / Brand
• Jackson Industries

• Year
• 1951 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 146536

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12BE6 12BA6 12AT6 50C5 35W4

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 60 Hz, 117V = 110 -120 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4.75 inch = 12.1 cm

• from Radiomuseum.org
• Model: DP-51 - Jackson Industries

• Shape
• Tablemodel, with any shape - general.

• Notes

• The Jackson Model DP-51 is an AC Operated radio-phonograph combination superheterodyne receiver with Loop Antenna.



• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Date 1-52, Set 156, Folder 7)

• Author
• Model page created by Egon Penker. See "Data change" for further contributors.
