Sansar all-in-one MB6

Janata Radios Ltd.; Calcutta (Kolkata)

Data
Forum
Pictures
Collections

  • Year
  • 1949/1950
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 223687

 Technical Specifications

  • Number of Tubes
  • 8
  • Main principle
  • Superheterodyne (common)
  • Power type and voltage
  • Line / Storage batteries (perhaps also batteries) / AC or DC 200 or 250 volt - or powerpack for storage battery 6 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Sansar all-in-one MB6 - Janata Radios Ltd.; Calcutta
  • Shape
  • Tablemodel, low profile (big size).
  • Dimensions (WHD)
  • 22 x 11 x 10 inch / 559 x 279 x 254 mm
  • Notes

  • The radio model Sansar all-in-one MB6, sold by Janata was at least designed in France. It has the following short wave bands: SW1: 11,13, 16,19, 25 and 31 meter, SW 2 is for 41 to 120 meter. Broadcast (Medium) is 550 kHz to 1550 kHz.
    Speciality: It uses in fact only 6 tubes: either on AC/DC the 25A6G is used. When the intenal (option) Power pack with a vibrator for 6-volt car battery is used then the 6V6G has to be but in (which is hold separately in the cabinet as a spare!) and the OZ4 comes in operation.425

  • Author
  • Model page created by Ernst Erb. See "Data change" for further contributors.
