• Year
  • 1970 ??
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 89960

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Line / Batteries (any type) / 220 / 12 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Nivico Videosphere 3240 - JVC - Victor Company of Japan,
  • Notes
  • JVC Nivico 3240 Videosphere;
    b/w TV with VHF-/UHF tuner.
    Add each TV standard and cabinet color at your price uploads!
    Sonderbauform eines S/W-TVs im Kugeldesign, verschiedene Farben wie in rot oder weiß bekannt, eingebaute Teleskopantenne, zusätzlicher Standfuß und Tragekette, Trommeltuner VHF Kanal 2 bis 12 und UHF 21 bis 69 nach CCIR B/G.
    Ergänzen Sie Ihre Preishochladungen mit dem Fernsehstandard und der Farbe!

  • Source of data
  • -- Collector info (Sammler)
  • Author
  • Model page created by a member from A. See "Data change" for further contributors.

 Collections | Museums | Literature


The model Nivico Videosphere is part of the collections of the following members.


Forum contributions about this model: JVC - Victor Company: Nivico Videosphere 3240

Threads: 1 | Posts: 1

The diagram I have uploaded doesn't quite specify if it belongs to any of the western versions of the TV, like the UK or the european edition. The AC legend says "50 Hz" so it probably belongs to the UK version (and somehow it should be moved there), but Japan uses both 50 and 60 Hz. I also have a copy in PDF format of the service manual, although it says "120v 60Hz".

Lisandro Pardo, 19.Aug.11
