Delmonico TFM-99U
JVC - Victor Company of Japan, Ltd.; Tokyo
- Country
- Japan
- Manufacturer / Brand
- JVC - Victor Company of Japan, Ltd.; Tokyo
- Year
- 1963 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 175226
Delmonico TFM-99U front
Delmonico TFM-99U dial
Delmonico TFM-99U schema
Delmonico TFM-99U bottom
- Number of Tubes
- 7
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 10 cm = 3.9 inch
- Power out
- 1.3 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Delmonico TFM-99U - JVC - Victor Company of Japan,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 440 x 190 x 150 mm / 17.3 x 7.5 x 5.9 inch
- Notes
-
Wave range AM: 535 - 1605 kc (1620 according to SAMS), FM: 88 - 108 mc. Ferrite antenna.
Made in Japan.
- Net weight (2.2 lb = 1 kg)
- 6 lb (6 lb 0 oz) / 2.724 kg
- Mentioned in
- Photofact Folder, Howard W. SAMS
- Author
- Model page created by Riccardo Coradazzi. See "Data change" for further contributors.
