Nivico FA6000T

Nivico FA6000T; JVC - Victor Company (ID = 209042) Radio

Nivico FA6000T; JVC - Victor Company (ID = 209043) Radio
Nivico FA6000T; JVC - Victor Company (ID = 1581760) Radio Nivico FA6000T; JVC - Victor Company (ID = 1406559) Radio
Nivico FA6000T; JVC - Victor Company (ID = 209009) Radio Nivico FA6000T; JVC - Victor Company (ID = 485117) Radio
Nivico FA6000T; JVC - Victor Company (ID = 1406556) Radio Nivico FA6000T; JVC - Victor Company (ID = 1406557) Radio
Nivico FA6000T; JVC - Victor Company (ID = 1406561) Radio Nivico FA6000T; JVC - Victor Company (ID = 1581761) Radio
Nivico FA6000T; JVC - Victor Company (ID = 1581762) Radio Nivico FA6000T; JVC - Victor Company (ID = 1581763) Radio
Use red slider bar for more.
Nivico FA6000T; JVC - Victor Company (ID = 1581760) Radio
JVC - Victor Company: Nivico FA6000T [Radio] ID = 1581760 933x946
Select picture or schematic to display from thumbnails on the right and click for download.
For model Nivico FA6000T, JVC - Victor Company of Japan, Ltd.; Tokyo

Country:  Japan
Manufacturer / Brand:  JVC - Victor Company of Japan, Ltd.; Tokyo
Year: 1968 ?? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11:
Main principle Superheterodyne (common); ZF/IF 455 kHz; 3 AF stage(s)
Wave bands Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
Details
Power type and voltage Dry Batteries / 6 x 1,5V Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.7 W (unknown quality)
from Radiomuseum.org Model: Nivico FA6000T - JVC - Victor Company of Japan,
Material Metal case
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 345 x 260 x 145 mm / 13.6 x 10.2 x 5.7 inch
Notes JVC Nivico FA6000T;
LW: 150 - 400 kHz,
AM: 535 - 1605 kHz,
SW1: 2 - 4 MHz,
SW2: 4.75 - 10 MHz,
SW3: 11.7 - 22 MHz,
FM: 87 - 108 MHz.
Net weight (2.2 lb = 1 kg) 7.5 kg / 16 lb 8.3 oz (16.52 lb)
Collectors' prices
Source of data - - Data from my own collection
Literature/Schematics (1) -- Schematic

Model page created by Pius Steiner. See "Data change" for further contributors.



All listed radios etc. from JVC - Victor Company of Japan, Ltd.; Tokyo
Here you find 808 models, 664 with images and 103 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
