Globe Speaker System GB-1E MARKIII

Globe Speaker System GB-1E MARKIII; JVC - Victor Company (ID = 2451965) Speaker-P Globe Speaker System GB-1E MARKIII; JVC - Victor Company (ID = 2451967) Speaker-P
Globe Speaker System GB-1E MARKIII; JVC - Victor Company (ID = 2451969) Speaker-P Globe Speaker System GB-1E MARKIII; JVC - Victor Company (ID = 576997) Speaker-P
Use red slider bar for more.
Globe Speaker System GB-1E MARKIII; JVC - Victor Company (ID = 2451965) Speaker-P
JVC - Victor Company: Globe Speaker System GB-1E MARKIII [Speaker-P] ID = 2451965 660x900
Select picture or schematic to display from thumbnails on the right and click for download.
For model Globe Speaker System GB-1E MARKIII, JVC - Victor Company of Japan, Ltd.; Tokyo:
Ebay UK auction item_113745524843 seller kerazylist

Country:  Japan
Manufacturer / Brand:  JVC - Victor Company of Japan, Ltd.; Tokyo
Year: 1977 Category: Loudspeaker, headphone or earphone
Wave bands - without
Details
Power type and voltage No Power needed
Loudspeaker 7 or more Loudspeakers
Power out
from Radiomuseum.org Model: Globe Speaker System GB-1E MARKIII - JVC - Victor Company of Japan,
Material Various materials
Shape Miscellaneous shapes - described under notes.
Notes

Acoustically damped two-way speaker with 8 loudspeakers designed as a round radiator  14⅜ inches in diameter.
Power Rating 40 watts RMS, 8 ohms, 20 - 20,000 Hz, 88 db/W/M.
Equipped with: 4 x 5 inch double coned bass-mid drivers and 4 x 2 inch horn tweeters.
Crossover frequency at 5000 Hz.
Optional: Stand Model GB-1EL

Akustisch bedämpfte Zweiwegbox mit 8 Lautsprecher ausgeführt als Rundstrahler mit 343mm Durchmesser.
40 Watt Sinus an 8 Ohm, 20 - 20.000 Hz, 88 db/W/M.
Bestückung: 4 x 130mm TT, 4 x 70mm HT-Konus. Frequenzweiche Übergang bei 5000 Hz.
Optional: Standfuss Modell GB-1EL

Net weight (2.2 lb = 1 kg) 28.6 lb (28 lb 9.6 oz) / 12.984 kg
Source of data -- Original prospect or advert
Mentioned in -- Original prospect or advert (1977 JVC HiFi-Katalog)
Literature/Schematics (1) - - Manufacturers Literature (JVC Service Manual 5303 GB-1E)

Model page created by Franz Scharner. See "Data change" for further contributors.
