• Country
• Japan

• Manufacturer / Brand
• JVC - Victor Company of Japan, Ltd.; Tokyo

• Year
• 1979/1980

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 143174

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: FM/AM Stereo Tuner T-X3 - JVC - Victor Company of Japan,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 450 x 89 x 364 mm / 17.7 x 3.5 x 14.3 inch

• Notes

• AM/FM-Stereo-Tuner mit breitem Abstimmwähler und linearer UKW Senderskala.

  Type: Mono/Stereo Tuner
  Tuning Bands: FM, AM
  Tuning Scale: Analogue
  FM Tuning Range: 87.5 to 108 MHz
  MW Tuning Range: 525 to 1605 kHz
  Sensitivity: 0.9µV (FM), 300µV (MW)
  Signal to Noise Ratio: 78dB (FM), 50dB (MW)
  Distortion: 0.15% (FM), 0.5% (MW)
  Selectivity: 70dB (FM), 40dB (MW)
  Frequency response: 30 Hz to 15 kHz (FM)
  Output: 600mV (FM), 400mV (MW)

• Net weight (2.2 lb = 1 kg)
• 4 kg / 8 lb 13 oz (8.811 lb)

• Source of data
• -- Original prospect or advert

• Author
• Model page created by Franz Scharner. See "Data change" for further contributors.
