• Year
  • 1967 ??
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 309169

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / AA: 2 x 1,5 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Bakelite or Plastics (type unknown)
  • from Radiomuseum.org
  • Model: Volt-Ohm-Milliammeter SK-20 - Kaise Electric Works, Ltd;
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Dimensions (WHD)
  • 86 x 130 x 38 mm / 3.4 x 5.1 x 1.5 inch
  • Net weight (2.2 lb = 1 kg)
  • 0.350 kg / 0 lb 12.3 oz (0.771 lb)
  • Author
  • Model page created by Carlos Saavedra. See "Data change" for further contributors.

 Collections | Museums | Literature

Collections

The model Volt-Ohm-Milliammeter is part of the collections of the following members.
