Nejva {Нейва} [Neywa] 7 Transistor

Kamensk-Uralsk Radio Works

  • Year
  • 1975 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 235422

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 7
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Dry Batteries / 1 x 9 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Nejva {Нейва} [Neywa] 7 Transistor - Kamensk-Uralsk Radio Works
  • Shape
  • Very small Portable or Pocket-Set (Handheld) < 8 inch.
  • Author
  • Model page created by Jaume Lorenzo-Felip. See "Data change" for further contributors.
