For model Multimeter 360-TRCX, Kamoshita Electronic Laboratory, Kamoden; Tokyo

Country:  Japan
Manufacturer / Brand:  Kamoshita Electronic Laboratory, Kamoden; Tokyo
Year: 1975 ?? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Dry Batteries / 2 x 1,5 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Multimeter 360-TRCX - Kamoshita Electronic
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 140 x 80 x 180 mm / 5.5 x 3.1 x 7.1 inch
Notes

Kamoden Multimeter 360-TRCX;

Messbereiche:

Gleichspannung: 250mV, 2.5V, 10V, 50V, 250V, 1000V,
(50kV über zusätzlichen Hochspannungs-Tastkopf)
Wechselspannung: 5V, 10V, 50V, 250V, 1000V
Gleichstrom: 10µA, 2.5mA, 25mA, 500mA, 10A
Wechselstrom: 10A
Widerstand (Ohm): 0.2 ~ 5k, 2 ~ 50k, 200 ~ 5M, 2k ~ 50M
Dezibel: -10dB ~ +16dB ~ +62 dB
Transistortest: hFE: 0 - 1000 NPN-PNP, Ico: 0 - 50µA NPN-PNP
Kapazität: 50pF ~3µF, 0.01µF ~ 50µF

Das Gerät ist "Made in Japan"

Net weight (2.2 lb = 1 kg) 1 kg / 2 lb 3.2 oz (2.203 lb)
Source of data -- Original-techn. papers.
