Abzweiger 2-fach EAD 12 BN 272340

Abzweiger 2-fach EAD 12 BN 272340; Kathrein; Rosenheim (ID = 1735950) Misc

Abzweiger 2-fach EAD 12 BN 272340; Kathrein; Rosenheim (ID = 1735951) Misc

Abzweiger 2-fach EAD 12 BN 272340; Kathrein; Rosenheim (ID = 1735952) Misc
Abzweiger 2-fach EAD 12 BN 272340; Kathrein; Rosenheim (ID = 1735949) Misc
Use red slider bar for more.
Abzweiger 2-fach EAD 12 BN 272340; Kathrein; Rosenheim (ID = 1735949) Misc
Kathrein; Rosenheim: Abzweiger 2-fach EAD 12 BN 272340 [Misc] ID = 1735949 748x589
Select picture or schematic to display from thumbnails on the right and click for download.
For model Abzweiger 2-fach EAD 12 BN 272340, Kathrein; Rosenheim:
Abbildung im Kathrein SAT Katalog 1994

Country:  Germany
Manufacturer / Brand:  Kathrein; Rosenheim
Year: 1994 ?? Category: Miscellaneous (Other, Various) - see notes
Wave bands Wave Bands given in the notes.
Details
Power type and voltage No Power needed
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Abzweiger 2-fach EAD 12 BN 272340 - Kathrein; Rosenheim
Material Metal case
Shape Miscellaneous shapes - described under notes.
Dimensions (WHD) 115 x 30 x 75 mm / 4.5 x 1.2 x 3 inch
Notes

Antennen Abzweiger 2-fach, 0,15-2050 MHz,

Abzweigdämpfung 10-11 dB,

Klemmanschlüsse.

Net weight (2.2 lb = 1 kg) 0.230 kg / 0 lb 8.1 oz (0.507 lb)
Mentioned in -- Original prospect or advert
