ADR-/DVB-Vorschaltumsetzer UWS 25 BN 260337

ADR-/DVB-Vorschaltumsetzer UWS 25 BN 260337; Kathrein; Rosenheim (ID = 1752886) Antenna

ADR-/DVB-Vorschaltumsetzer UWS 25 BN 260337; Kathrein; Rosenheim (ID = 1752887) Antenna
ADR-/DVB-Vorschaltumsetzer UWS 25 BN 260337; Kathrein; Rosenheim (ID = 1752885) Antenna
Use red slider bar for more.
ADR-/DVB-Vorschaltumsetzer UWS 25 BN 260337; Kathrein; Rosenheim (ID = 1752885) Antenna
Kathrein; Rosenheim: ADR-/DVB-Vorschaltumsetzer UWS 25 BN 260337 [Antenna] ID = 1752885 346x245
Select picture or schematic to display from thumbnails on the right and click for download.
For model ADR-/DVB-Vorschaltumsetzer UWS 25 BN 260337, Kathrein; Rosenheim:
Abbildung im Kathrein SAT Katalog 1995/96

Country:  Germany
Manufacturer / Brand:  Kathrein; Rosenheim
Year: 1995 ?? Category: Antenna (Aerial) or Coupler
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle RF Converter/Adapter (not voltage converter)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Powered by external power supply or a main unit. / DC 12-20 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: ADR-/DVB-Vorschaltumsetzer UWS 25 BN 260337 - Kathrein; Rosenheim
Shape Miscellaneous shapes - described under notes.
Notes

Blockumsetzer für ADR-/DVB-Signale vom Hyperband 300-520MHz auf 1400-1620MHz,

dadurch wird der Einsatz von ADR- oder DVB-Satreceivern in Kabelanlagen ermöglicht.

Mentioned in -- Original prospect or advert

Model page created by a member from D. See "Data change" for further contributors.
