Astra 1 D-Umsetzer UWS 22 260317

Astra 1 D-Umsetzer UWS 22 260317; Kathrein; Rosenheim (ID = 1752879) Antenna

Astra 1 D-Umsetzer UWS 22 260317; Kathrein; Rosenheim (ID = 1752880) Antenna
Astra 1 D-Umsetzer UWS 22 260317; Kathrein; Rosenheim (ID = 1752878) Antenna
Use red slider bar for more.
Astra 1 D-Umsetzer UWS 22 260317; Kathrein; Rosenheim (ID = 1752878) Antenna
Kathrein; Rosenheim: Astra 1 D-Umsetzer UWS 22 260317 [Antenna] ID = 1752878 450x246
Select picture or schematic to display from thumbnails on the right and click for download.
For model Astra 1 D-Umsetzer UWS 22 260317, Kathrein; Rosenheim:
Abbildung im Kathrein SAT Katalog 1995/96

Country:  Germany
Manufacturer / Brand:  Kathrein; Rosenheim
Year: 1995 ?? Category: Antenna (Aerial) or Coupler
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle RF Converter/Adapter (not voltage converter)
Wave bands SAT-IF
Details
Power type and voltage Powered by external power supply or a main unit. / DC 12-20 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Astra 1 D-Umsetzer UWS 22 260317 - Kathrein; Rosenheim
Material Metal case
Shape Miscellaneous shapes - described under notes.
Notes

Umsetzer für ältere LNC mit LO 10,0GHz, der untere Astra 1 D-Bereich wird nach oben versetzt.

Mentioned in -- Original prospect or advert

Model page created by a member from D. See "Data change" for further contributors.
