• Country
• Germany

• Manufacturer / Brand
• Kathrein; Rosenheim

• Year
• 1999 ??

• Category
• RF (Radio Frequency-) Amplifier

• Radiomuseum.org ID
• 261494

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• Radio Frequency Amplification only

• Wave bands
• SAT-IF

• Power type and voltage
• Powered by external power supply or a main unit. / DC 18 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Breitbandverstärker VWS 220 BN 230639 - Kathrein; Rosenheim

• Dimensions (WHD)
• 90 x 79 x 45 mm / 3.5 x 3.1 x 1.8 inch

• Notes

• Breitbandverstärker mit 2 unabhängigen Verstärkerzügen 950-3000MHz,

  Verstärkung 6-12dB, kompensiert und entzerrt die Dämpfung von 30m Kabel.

• Net weight (2.2 lb = 1 kg)
• 0.3 kg / 0 lb 10.6 oz (0.661 lb)
