Satelliten-Receiver UFD 500 BN 260486

Kathrein; Rosenheim

  • Year
  • 1999 ??
  • Category
  • Digital terrestrial, Internet and SAT receiver (also analogue)
  • Radiomuseum.org ID
  • 261872

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • PLL, Phase-locked loop; ZF/IF 479500 kHz
  • Wave bands
  • SAT-IF
  • Details
  • Remote Control (with wire or wireless)
  • Power type and voltage
  • Alternating Current supply (AC) / 230 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Satelliten-Receiver UFD 500 BN 260486 - Kathrein; Rosenheim
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 350 x 68 x 270 mm / 13.8 x 2.7 x 10.6 inch
  • Notes
  • DVB-Satreceiver, 920-2150MHz,

    600 Programmspeicher,

    DiSEqC-Steuerung,

    Bildformaterkennung 3:4 / 16:9,

    IR-Fernsteuerung.

  • Net weight (2.2 lb = 1 kg)
  • 3.6 kg / 7 lb 14.9 oz (7.93 lb)
  • Mentioned in
  • -- Original prospect or advert
  • Author
  • Model page created by a member from D. See "Data change" for further contributors.
