• Country
• Germany

• Manufacturer / Brand
• Kathrein; Rosenheim

• Year
• 2002 ??

• Category
• Digital terrestrial, Internet and SAT receiver (also analogue)

• Radiomuseum.org ID
• 262338

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• PLL, Phase-locked loop

• Wave bands
• SAT-IF

• Details
• Radio Control (+Remote Wire etc)

• Power type and voltage
• Alternating Current supply (AC) / AC 100-240 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Satelliten-Receiver UFD 505 BN 20210008 - Kathrein; Rosenheim

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 335 x 68 x 285 mm / 13.2 x 2.7 x 11.2 inch

• Notes

• DVB-Sat-Receiver, 920-2150MHz,

  4000 Programmspeicher,
  DiSEqC-Steuerung, Tone Burst, 22 kHz,
  Sat-ZF Durchschleifbetrieb,
  OSD in 8 Sprachen.

• Net weight (2.2 lb = 1 kg)
• 2.6 kg / 5 lb 11.6 oz (5.727 lb)
