• Country
• Germany

• Manufacturer / Brand
• Kathrein; Rosenheim

• Year
• 1994 ??

• Category
• Antenna (Aerial) or Coupler

• Radiomuseum.org ID
• 259329

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Main principle
• RF Converter/Adapter (not voltage converter)

• Wave bands
• SAT-IF

• Power type and voltage
• Powered by external power supply or a main unit. / DC 15 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Speisesystem UAS 150 BN 267562 - Kathrein; Rosenheim

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 254 x 96 x 97 mm / 10 x 3.8 x 3.8 inch

• Notes

• LNC für TV-Sat, 11,7 - 12,5 GHz, Polarisation zirkular linksdrehend,

  Verstärkung 47 dB, LO 10,750 GHz,

  Ausgang 950 - 1750 MHz,

  geeignet für Offset-Spiegel.

• Net weight (2.2 lb = 1 kg)
• 1.4 kg / 3 lb 1.3 oz (3.084 lb)

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by a member from D. See "Data change" for further contributors.
