• Country
• Germany

• Manufacturer / Brand
• Kathrein; Rosenheim

• Year
• 1997 ??

• Category
• Antenna (Aerial) or Coupler

• Radiomuseum.org ID
• 260851

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• SAT-IF

• Power type and voltage
• Powered by external power supply or a main unit. / DC 11-19 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Umschaltmatrize EXR 204 BN 273277 - Kathrein; Rosenheim

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 90 x 79 x 47 mm / 3.5 x 3.1 x 1.9 inch

• Notes

• 4-fach Umschaltmatrize für Sat-ZF, 2 Eingänge vertikal + horizontal, 4 Ausgänge, 950-2400MHz,

  eingebaute Verstärkerzüge gleichen die Verteilungsverluste weitgehend aus,

  Fernspeisung und vert/hor. Umschaltung sowie LNC-Fernspeisung über Vert /Hor-Zweig mit 14V/18V erfolgt durch die angeschlossenen Receiver,

  F-Buchsen.







• Net weight (2.2 lb = 1 kg)
• 0.4 kg / 0 lb 14.1 oz (0.881 lb)

• Mentioned in
• -- Original prospect or advert

• Author
• Model page created by a member from D. See "Data change" for further contributors.
