• Country
• Germany

• Manufacturer / Brand
• Kathrein; Rosenheim

• Year
• 1999 ??

• Category
• Antenna (Aerial) or Coupler

• Radiomuseum.org ID
• 261666

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• SAT-IF

• Power type and voltage
• Powered by external power supply or a main unit. / DC 12-19 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Umschaltmatrize EXR 514 BN 273353 - Kathrein; Rosenheim

• Shape
• Miscellaneous shapes - described under notes.

• Dimensions (WHD)
• 94 x 112 x 47 mm / 3.7 x 4.4 x 1.9 inch

• Notes

• Umschaltmatrize, 4x Sat-ZF+Terr. auf 4 Teilnehmer,

  47-862MHz, 950-2400MHz, 22kHz Umschaltung,

  die Stromversorgung übernehmen die angeschlossenen Receiver,

  LNC Speisung über separates optionales Netzteil .

• Net weight (2.2 lb = 1 kg)
• 0.550 kg / 1 lb 3.4 oz (1.211 lb)
