RTX400

RTX400; Kirksaeter, (ID = 292780) Radio RTX400; Kirksaeter, (ID = 1525857) Radio
RTX400; Kirksaeter, (ID = 1525883) Radio RTX400; Kirksaeter, (ID = 1525891) Radio
RTX400; Kirksaeter, (ID = 1602473) Radio
Use red slider bar for more.
RTX400; Kirksaeter, (ID = 292780) Radio
Kirksaeter,: RTX400 [Radio] ID = 292780 622x369
Select picture or schematic to display from thumbnails on the right and click for download.
For model RTX400, Kirksaeter, Düsseldorf:
FS1966/9

Country:  Germany
Manufacturer / Brand:  Kirksaeter, Düsseldorf
Brand

Audioson
Year: 1966/1967 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 44:
schematic requested
Main principle Superhet with RF-stage
Tuned circuits 14 FM circuit(s)
Wave bands FM Broadcast Band Only
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: RTX400 - Kirksaeter, Düsseldorf
Material Wooden case
Shape Book-shelf unit.
Dimensions (WHD) 420 x 135 x 260 mm / 16.5 x 5.3 x 10.2 inch
Notes

Audioson FM-Mono/Stereo-Receiver, Ausgangsleistung 80 Watt, 1965er Version wird mit Pout 60 Watt angegeben; externe Eingänge, Teak-, Nußbaum- oder Palisander-Ausführung.
Als getrennte Einheiten in gleichen Abmessungen lieferbar: Verstärker TX500 um 980,- DM und Tuner RT100 um 720,- DM.
Verstärkerteil: 31 Silizium-Transistoren, 6 Zenerdioden, 1 Si-Diode.
Tunerteil: 13 Transistoren, 10 Dioden

Net weight (2.2 lb = 1 kg) 13 kg / 28 lb 10.1 oz (28.634 lb)
Price in first year of sale 1,598.00 DM
Mentioned in Funkschau (1966 Heft 9 Seite 661)
Literature/Schematics (1) HiFi Jahrbuch III 1967/68 Seite 127

Model page created by a member from A. See "Data change" for further contributors.
