For model HiFi Stereo-Endverstärker SA 600, Klein & Hummel; Stuttgart-Kemnat (Marke: K+H, Telewatt, Schwabenradio):
Titelbild Produktblatt

Country:  Germany
Manufacturer / Brand:  Klein & Hummel; Stuttgart-Kemnat (Marke: K+H, Telewatt, Schwabenradio)
Year: 1980 Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
schematic requested
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 400 W (680 W max.)
from Radiomuseum.org Model: HiFi Stereo-Endverstärker SA 600 - Klein & Hummel; Stuttgart-
Material Metal case
Shape Rack
Dimensions (WHD) 483 x 132.5 x 360 mm / 19 x 5.2 x 14.2 inch
Notes

Hi-Fi-Stereo-Endverstärker,

laststabil bis minimal 1 Ohm,

Einschalt-Strombegrenzung,

Schutzschaltung für Übertemperatur und Gleichspannung am Ausgang.

Net weight (2.2 lb = 1 kg) 21.7 kg / 47 lb 12.8 oz (47.797 lb)
Mentioned in -- Original prospect or advert

Model page created by a member from D. See "Data change" for further contributors.
