Echolette LE2/N

Echolette LE2/N; Echolette Marke / (ID = 2126043) Speaker-P
Echolette LE2/N; Echolette Marke / (ID = 388143) Speaker-P Echolette LE2/N; Echolette Marke / (ID = 388144) Speaker-P
Echolette LE2/N; Echolette Marke / (ID = 388145) Speaker-P Echolette LE2/N; Echolette Marke / (ID = 388146) Speaker-P
Echolette LE2/N; Echolette Marke / (ID = 588705) Speaker-P Echolette LE2/N; Echolette Marke / (ID = 588707) Speaker-P
Echolette LE2/N; Echolette Marke / (ID = 588709) Speaker-P Echolette LE2/N; Echolette Marke / (ID = 588711) Speaker-P
Use red slider bar for more.
Echolette LE2/N; Echolette Marke / (ID = 388143) Speaker-P
Echolette Marke /: Echolette LE2/N [Speaker-P] ID = 388143 525x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Echolette LE2/N, Echolette (Marke / brand); München

Country:  Germany
Manufacturer / Brand:  Echolette (Marke / brand); München
Brand

Klemt-Echolette
Year: 1960 ?? Category: Loudspeaker, headphone or earphone
Wave bands - without
Details
Power type and voltage No Power needed
Loudspeaker 4 Loudspeakers
Power out 35 W (unknown quality)
from Radiomuseum.org Model: Echolette LE2/N - Echolette Marke / brand;
Material Leather / canvas / plastic - over other material
Shape Console with any shape - in general
Dimensions (WHD) 470 x 590 x 240 mm / 18.5 x 23.2 x 9.4 inch
Notes Gesangslautsprecher, 1 x 12" ISOPHON - Tieftöner P 30/37A bzw. P30/A90, 1 x Mittel-Hochtonwanne ISOPHON DHB 6/2-10, Übertragungsbereich: 30 Hz bis 20 kHz
Net weight (2.2 lb = 1 kg) 15 kg / 33 lb 0.6 oz (33.04 lb)

Model page created by Peter Böhm. See "Data change" for further contributors.
