Regent 600 G

Regent 600 G; Klingenthaler (ID = 517754) Ampl/Mixer Regent 600 G; Klingenthaler (ID = 1292267) Ampl/Mixer
Regent 600 G; Klingenthaler (ID = 2110934) Ampl/Mixer Regent 600 G; Klingenthaler (ID = 2110935) Ampl/Mixer
Regent 600 G; Klingenthaler (ID = 2110936) Ampl/Mixer Regent 600 G; Klingenthaler (ID = 2110938) Ampl/Mixer
Use red slider bar for more.
Regent 600 G; Klingenthaler (ID = 517754) Ampl/Mixer
Klingenthaler: Regent 600 G [Ampl/Mixer] ID = 517754 933x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Regent 600 G, Klingenthaler Harmonikawerke, VEB; Klingenthal (Ostd.) (Vermona)

Country:  Germany
Manufacturer / Brand:  Klingenthaler Harmonikawerke, VEB; Klingenthal (Ostd.) (Vermona)
alternative name

Musikelektronik Klingenthal (VEB) (Ostd.)
Year: 1970 ?? Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) Semiconductors present.
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 220; 240 Volt
Loudspeaker - This model requires external speaker(s).
Power out 50 W (unknown quality)
from Radiomuseum.org Model: Regent 600 G - Klingenthaler Harmonikawerke,
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 530 x 290 x 350 mm / 20.9 x 11.4 x 13.8 inch
Notes Der Regent 600 G hat eine Ausgangsleistung von 50 Watt Sinus an 2× 12 Ohm.
Eingänge: Summenregler Volumen und Lautstärke, 5 regelbare Eingänge mit Höhen-, Mitten-, Tiefenreglung.
Net weight (2.2 lb = 1 kg) 22 kg / 48 lb 7.3 oz (48.458 lb)
Collectors' prices

Model page created by Wolfgang Lill. See "Data change" for further contributors.



All listed radios etc. from Klingenthaler Harmonikawerke, VEB; Klingenthal (Ostd.) (Vermona)
Here you find 79 models, 59 with images and 31 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
