For model Knight Space Spanner, Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)

Country:  United States of America (USA)
Manufacturer / Brand:  Allied Radio Corp. (Knight, Roamer, Wextark); Chicago (IL)
Year: 1956–1964 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: 12AT7 50C5 35W4
Main principle TRF with regeneration
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 110-120 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: Knight Space Spanner - Allied Radio Corp. Knight,
Material Leather / canvas / plastic - over other material
Shape Tablemodel without bush buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 11 x 7.75 x 6 inch / 279 x 197 x 152 mm
Notes

The Knight Space Spanner is a 2-band shortwave receiver in kit form.  The initial offer only included the chassis with an option for the cabinet for an additional $2.90.  Later years (1959 - 1964) only offered the combined package of chassis and cabinet.

The dimensions and weights are for the combined chassis and cabinet.

Net weight (2.2 lb = 1 kg) 4 lb 6 oz (4.375 lb) / 1.986 kg
Price in first year of sale 14.00 $
Mentioned in Boat Anchor Manual Archive
Literature/Schematics (1) Allied Radio Catalog Nº 150, 1956

Model page created by Vitor Oliveira. See "Data change" for further contributors.
