KT-62

KT-62; TEN brand, Kobe (ID = 2514448) Radio KT-62; TEN brand, Kobe (ID = 2514464) Radio
KT-62; TEN brand, Kobe (ID = 2514465) Radio KT-62; TEN brand, Kobe (ID = 2514467) Radio
KT-62; TEN brand, Kobe (ID = 2514469) Radio KT-62; TEN brand, Kobe (ID = 2514472) Radio
Use red slider bar for more.
KT-62; TEN brand, Kobe (ID = 2514448) Radio
TEN brand, Kobe: KT-62 [Radio] ID = 2514448 1400x922
Select picture or schematic to display from thumbnails on the right and click for download.
For model KT-62, TEN (brand), Kobe Kogyo Corporation; Kobe:
Seriennummer 4864

Country:  Japan
Manufacturer / Brand:  TEN (brand), Kobe Kogyo Corporation; Kobe
Year: 1958 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: 2S30 2S31 2S31 2S32 2S33 2S33 KV-1 1NA4
Main principle Superheterodyne (common); ZF/IF 455 kHz
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: KT-62 - TEN brand, Kobe Kogyo
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 118 x 76 x 33 mm / 4.6 x 3 x 1.3 inch
Notes Earphone jack.
Net weight (2.2 lb = 1 kg) 0.350 kg / 0 lb 12.3 oz (0.771 lb)

Model page created by Bernhard Nagel. See "Data change" for further contributors.
