Rejectostat KB 666A

Rejectostat KB 666A; Kolster Brandes Ltd. (ID = 1983374) Radio

Rejectostat KB 666A; Kolster Brandes Ltd. (ID = 1983375) Radio

Rejectostat KB 666A; Kolster Brandes Ltd. (ID = 1983376) Radio

Rejectostat KB 666A; Kolster Brandes Ltd. (ID = 1983377) Radio

Rejectostat KB 666A; Kolster Brandes Ltd. (ID = 1015800) Radio

Rejectostat KB 666A; Kolster Brandes Ltd. (ID = 1015802) Radio

Rejectostat KB 666A; Kolster Brandes Ltd. (ID = 1015803) Radio
Use red slider bar for more.
Rejectostat KB 666A; Kolster Brandes Ltd. (ID = 1983374) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Great Britain (UK)
Manufacturer / Brand:  Kolster Brandes Ltd. (KB, K.B., ITT); Foots Cray; GB
Year: 1933–1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 9A1 8A1 9A1 11A2 7A2 R2
Main principle Superhet with RF-stage; ZF/IF 130 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 100-130 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 8 inch = 20.3 cm
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Rejectostat KB 666A - Kolster Brandes Ltd. KB, K.B.,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 25 x 14.75 x 11.25 inch / 635 x 375 x 286 mm
Notes Available with stand. Walnut cabinet, black fittings & diamond speaker aperture. Micromesh valves, alternative Mullard valves are VP4, SP4, VP4, TDD4, Pen4VA, DW3. Same chassis used in models K-B 666, B, & C. Recommended aerial length 75-100 feet with "Rejectostat" system.
Net weight (2.2 lb = 1 kg) 40 lb (40 lb 0 oz) / 18.160 kg
Price in first year of sale 160.00 Hfl
Source of data Technisch- Commercieel - Radio Vademecum Staleman
Literature/Schematics (1) Trader Sheets 13 & 568

Model page created by John Koster. See "Data change" for further contributors.
