For model KB 830 Domestic, Kolster Brandes Ltd. (KB, K.B., ITT); Foots Cray; GB:
This example appears to be in original condition

Country:  Great Britain (UK)
Manufacturer / Brand:  Kolster Brandes Ltd. (KB, K.B., ITT); Foots Cray; GB
Year: 1939 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 20D2 9D2 11D5 7D5 R2
Main principle Superheterodyne (common); ZF/IF 464 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 100-250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: KB 830 [Domestic] - Kolster Brandes Ltd. KB, K.B.,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 530 x 317 x 295 mm / 20.9 x 12.5 x 11.6 inch
Notes A similar chassis is fitted in the KB 831 console radio.
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (439)

Model page created by Howard Craven. See "Data change" for further contributors.
