GR10/1

GR10/1; Kolster Brandes Ltd. (ID = 532728) Radio

GR10/1; Kolster Brandes Ltd. (ID = 532731) Radio
GR10/1; Kolster Brandes Ltd. (ID = 208278) Radio GR10/1; Kolster Brandes Ltd. (ID = 692004) Radio
GR10/1; Kolster Brandes Ltd. (ID = 692007) Radio GR10/1; Kolster Brandes Ltd. (ID = 692008) Radio
GR10/1; Kolster Brandes Ltd. (ID = 692009) Radio GR10/1; Kolster Brandes Ltd. (ID = 692013) Radio
GR10/1; Kolster Brandes Ltd. (ID = 1391075) Radio GR10/1; Kolster Brandes Ltd. (ID = 1391077) Radio
GR10/1; Kolster Brandes Ltd. (ID = 1391079) Radio GR10/1; Kolster Brandes Ltd. (ID = 1391082) Radio
Use red slider bar for more.
GR10/1; Kolster Brandes Ltd. (ID = 208278) Radio
Kolster Brandes Ltd.: GR10/1 [Radio] ID = 208278 603x548
Select picture or schematic to display from thumbnails on the right and click for download.
For model GR10/1, Kolster Brandes Ltd. (KB, K.B., ITT); Foots Cray; GB

Country:  Great Britain (UK)
Manufacturer / Brand:  Kolster Brandes Ltd. (KB, K.B., ITT); Foots Cray; GB
Year: 1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6BE6 6BA6 6AT6 6BW6 6X4
Main principle Superheterodyne (common); ZF/IF 422 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 10 inch = 25.4 cm
Power out 2.5 W (3 W max.)
from Radiomuseum.org Model: GR10/1 - Kolster Brandes Ltd. KB, K.B.,
Material Wooden case
Shape Tablemodel, with any shape - general.
Source of data Radio And Television Servicing books (R&TVS)
Literature/Schematics (1) Radio And Television Servicing books (R&TVS) (Vol I, Pre 1953. Page 288.)

Model page created by Keith Staines. See "Data change" for further contributors.



All listed radios etc. from Kolster Brandes Ltd. (KB, K.B., ITT); Foots Cray; GB
Here you find 415 models, 367 with images and 253 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
