• Country
• Great Britain (UK)

• Manufacturer / Brand
• Kolster Brandes Ltd. (KB, K.B., ITT); Foots Cray; GB

• Year
• 1938

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 198941

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• X41 or 20A1 9D2 11D3 7D5 R2

• Main principle
• Superheterodyne (common); ZF/IF 464 kHz

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 220; 225; 250 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: KB 730 [British valves, Without Magic Eye] - Kolster Brandes Ltd. KB, K.B.,

• Shape
• Tablemodel, low profile (big size).

• Notes
• UK version. There are two other KB-730 models KB 730 var. 1 and KB 730 var.2 with an additional magic eye valve.

• Source of data
• -- Schematic

• Literature/Schematics (1)
• Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (365)

• Author
• Model page created by Antonio Martins-Pais. See "Data change" for further contributors.
