Masterpiece KB 207 2 valve

• Country
• Great Britain (UK)

• Manufacturer / Brand
• Kolster Brandes Ltd. (KB, K.B., ITT); Foots Cray; GB

• Year
• 1930

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 77572

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 2

• Valves / Tubes
• PM1HF 220P

• Main principle
• TRF with regeneration

• Tuned circuits
• 1 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage and/or dry batteries / 2 & 80 & 90 & -6 Volt

• Loudspeaker
• Magnetic loudspeaker (reed) generic.

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Masterpiece KB 207 [2 valve] - Kolster Brandes Ltd. KB, K.B.,

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Dimensions (WHD)
• 7.25 x 7.25 x 7.25 inch / 184 x 184 x 184 mm

• Notes
• given away as a "free gift" by Godfrey Phillips Ltd. for 500 BVD cigarette coupons (one in every pack of ten).

• Net weight (2.2 lb = 1 kg)
• 2.2 kg / 4 lb 13.5 oz (4.846 lb)

• Source of data
• Radio! Radio!

• Documents regarding this model

• Author
• Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
