Rejectostat KB 430

Rejectostat KB 430; Kolster Brandes Ltd. (ID = 1025188) Radio

Rejectostat KB 430; Kolster Brandes Ltd. (ID = 1025189) Radio
Rejectostat KB 430; Kolster Brandes Ltd. (ID = 2052523) Radio Rejectostat KB 430; Kolster Brandes Ltd. (ID = 195837) Radio
Rejectostat KB 430; Kolster Brandes Ltd. (ID = 195836) Radio Rejectostat KB 430; Kolster Brandes Ltd. (ID = 2052524) Radio
Rejectostat KB 430; Kolster Brandes Ltd. (ID = 2052525) Radio
Use red slider bar for more.
Rejectostat KB 430; Kolster Brandes Ltd. (ID = 2052523) Radio
Kolster Brandes Ltd.: Rejectostat KB 430 [Radio] ID = 2052523 1280x1476
Select picture or schematic to display from thumbnails on the right and click for download.
For model Rejectostat KB 430, Kolster Brandes Ltd. (KB, K.B., ITT); Foots Cray; GB

Country:  Great Britain (UK)
Manufacturer / Brand:  Kolster Brandes Ltd. (KB, K.B., ITT); Foots Cray; GB
Year: 1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 9D2 or 13VPA HL13C 7D6 1D5_rectifier or 40SUA
Main principle TRF with regeneration
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage AC/DC-set / 200-270 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: Rejectostat KB 430 - Kolster Brandes Ltd. KB, K.B.,
Material Wooden case
Shape Tablemodel, high profile (upright - NOT Cathedral nor decorative).
Dimensions (WHD) 13.5 x 16 x 9 inch / 343 x 406 x 229 mm
Source of data Radio! Radio!
Mentioned in Technisch- Commercieel - Radio Vademecum Staleman
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (77)

Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
