Bremen 27150 Art.Nr. 821/06

Neckermann-Versand KG; Frankfurt a.M.

  • Year
  • 1966 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 120336
    • Brand: Twen Tone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Number of Transistors
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz; 2 AF stage(s)
  • Tuned circuits
  • 7 AM circuit(s)     10 FM circuit(s)
  • Wave bands
  • Broadcast, Long Wave, Short Wave plus FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Bremen 27150 Art.Nr. 821/06 - Neckermann-Versand KG;
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 480 x 235 x 185 mm / 18.9 x 9.3 x 7.3 inch
  • Notes
  • Bremen Art. Nr. 821/06 (Körting Nr. 27 150) ist ein 4-Wellen-Rundfunkempfänger für Netzbetrieb.

    Für das gleiche Modell mit andersfarbiger Skala siehe Bremen Art.Nr. 821/292.

    Hergestellt von Körting Radio Werke G.m.b.H. für Neckermann Versand K.G.

  • Net weight (2.2 lb = 1 kg)
  • 5 kg / 11 lb 0.2 oz (11.013 lb)
  • Price in first year of sale
  • 169.00 DM
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Peter Hartig. See "Data change" for further contributors.
