Combiné de Table Radio-Phono Amica 70 30 253

Combiné de Table Radio-Phono Amica 70 30 253; Körting-Radio; (ID = 2358340) Radio

Combiné de Table Radio-Phono Amica 70 30 253; Körting-Radio; (ID = 2358341) Radio

Combiné de Table Radio-Phono Amica 70 30 253; Körting-Radio; (ID = 2358342) Radio
Combiné de Table Radio-Phono Amica 70 30 253; Körting-Radio; (ID = 2053307) Radio Combiné de Table Radio-Phono Amica 70 30 253; Körting-Radio; (ID = 2053308) Radio
Use red slider bar for more.
Combiné de Table Radio-Phono Amica 70 30 253; Körting-Radio; (ID = 2053307) Radio
Körting-Radio;: Combiné de Table Radio-Phono Amica 70 30 253 [Radio] ID = 2053307 1000x618
Select picture or schematic to display from thumbnails on the right and click for download.
For model Combiné de Table Radio-Phono Amica 70 30 253, Körting-Radio; Leipzig, später Grassau

Country:  Germany
Manufacturer / Brand:  Körting-Radio; Leipzig, später Grassau
alternative name

Dietz & Ritter GmbH, Dr.
Year: 1970 ? Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 11:
Main principle Superheterodyne (common)
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Combiné de Table Radio-Phono Amica 70 30 253 - Körting-Radio; Leipzig, später
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 560 x 170 x 270 mm / 22 x 6.7 x 10.6 inch
Notes

5 Diodes
1 Redresseur (Gleichrichter)

FM (UKW)  87,3 - 104 MHz
OC (KW)     5,8 - 7,4 MHz
PO (MW)     510 - 1620 kHz
GO (LW)     145 - 355 kHz

Tourne-disques Philips GC 032/12,capsule GP306

Mentioned in -- Original prospect or advert

Model page created by João-Afonso Santos. See "Data change" for further contributors.
