• Country
• Germany

• Manufacturer / Brand
• Körting-Radio; Leipzig, später Grassau

• Year
• 1932–1934

• Category
• Loudspeaker, headphone or earphone

• Radiomuseum.org ID
• 130475

• • alternative name: Dietz & Ritter GmbH, Dr.

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• RGN504

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 120; 220 V or 110; 125; 150; 220 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 18 cm = 7.1 inch

• Power out
• 2 W (max.)

• Material
• Metal case

• from Radiomuseum.org
• Model: Excello Domette W - Körting-Radio; Leipzig, später

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 350 x 340 x 180 mm / 13.8 x 13.4 x 7.1 inch

• Notes

• Körting Domette Lautsprecher im Edelholzgehäuse.
  Eingebauter Universaltransformator für alle gebräuchlichen Endröhren.

  Preis ohne Röhre, zusätzlich 1x RGN504: 7,20 RM.

• Net weight (2.2 lb = 1 kg)
• 7.1 kg / 15 lb 10.2 oz (15.639 lb)

• Price in first year of sale
• 80.00 RM

• Source of data
• -- Original prospect or advert

• Mentioned in
• Zeitschrift "Funk Post" April 1932

• Literature/Schematics (1)
• Katalog Radio-Schnorr Nr.54, 1934

• Author
• Model page created by a member from A. See "Data change" for further contributors.
