• Country
• Czechoslovakia

• Manufacturer / Brand
• Jiskra, Výrobní Družstvo Strojníků a Nástrojárů; Pardubice

• Year
• 1958 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 122659

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• ECH81 EBF89 ECL82 6Z31

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 110; 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Power out
• 3.5 W (unknown quality)

• Material
• Bakelite or Plastics (type unknown)

• from Radiomuseum.org
• Model: 358A - Jiskra, Výrobní Družstvo

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 305 x 205 x 150 mm / 12 x 8.1 x 5.9 inch

• Notes

• Export version produced for trade company KOVO.

• Net weight (2.2 lb = 1 kg)
• 3.9 kg / 8 lb 9.4 oz (8.59 lb)

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Jozef Brughmans †. See "Data change" for further contributors.
