For model UKW-Kristallette TU66 106, Kristallwerk Graz (auch Rainer):
Kristallwerk UKW-Kristallette TU66.106

Country:  Austria
Manufacturer / Brand:  Kristallwerk Graz (auch Rainer)
Year: 1966/1967 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 10: AF106 AF125 AF126 AF126 AF126 AF126 AC125 AC125 AC128 AC128
Main principle Superheterodyne (common); ZF/IF 452/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast (BC) and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC)
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 1 W (unknown quality)
from Radiomuseum.org Model: UKW-Kristallette TU66 106 - Kristallwerk Graz auch Rainer
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 435 x 218 x 140 mm / 17.1 x 8.6 x 5.5 inch
Notes

UKW-Kristallette TU66 106 ist ein UKW-MW Transistor-Superhet-Empfänger für Wechselstromanschluss.

Eingebaute Ferritantenne, Anschluss für UKW-Dipol, Tonabnehmer und Aussenlautsprecher.

Net weight (2.2 lb = 1 kg) 3.3 kg / 7 lb 4.3 oz (7.269 lb)
Source of data Radiokatalog Band 2, Ernst Erb
Literature/Schematics (1) -- Schematic
