For model Function Generator 2000, Krohn-Hite Corp.; Cambridge and Brockton, MA:
Peak volts knob not original

Country:  United States of America (USA)
Manufacturer / Brand:  Krohn-Hite Corp.; Cambridge and Brockton, MA
Year: 1975 ?? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 90-132; 180-264 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Function Generator 2000 - Krohn-Hite Corp.; Cambridge
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 220 x 132 x 300 mm / 8.7 x 5.2 x 11.8 inch
Notes Funktionsgenerator von 0,03 Hz bis 30 MHz in 8 Stufen schaltbar, dazwischen stetig regelbar. Sinus, Dreieck, Rechteck, pos. und neg. Pulse, Symmetrie und DC-Offset regelbar. Main Output 0-15 Volt an 50 Ohm, zusätzlich -20, -40 und -60 dB über Drucktasten schaltbar. TTL an 50 Ohm. VC in und CV out. Sync. Eingang. Signal ground "chassis oder floating" schaltbar. Zusätzlich zur 120/240 Volt Umschaltung ist ein "Norm. und Low" Umschalter vorhanden. Damit werden Netzspannungen zwischen 90 bis 132 oder 180 bis 264 Volt abgedeckt.
Net weight (2.2 lb = 1 kg) 4.540 kg / 10 lb 0 oz (10 lb)
Collectors' prices

Model page created by Otto Frosinn. See "Data change" for further contributors.
