• Country
• Spain

• Manufacturer / Brand
• LME Laboratorio de Metrologia Electrónica; Barcelona

• Year
• 1963

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 171066

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 6L6 6L6 6BH6 6X4 0A2 0A2

• Wave bands
• - without

• Details
• Power Supply (not only Batt.El.)

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Fuente Alimentación FE-5-A - LME Laboratorio de Metrologia

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 310 x 230 x 220 mm / 12.2 x 9.1 x 8.7 inch

• Notes
• 0-400 V variable @ 100 mA.
  0-100 V para polarización @ 1mA.
  Salida conmutable para filamentos entre 1,7 y 117 V.

  Precio catálogo 1967: 9.920 Pts (ESP).

• Net weight (2.2 lb = 1 kg)
• 10 kg / 22 lb 0.4 oz (22.026 lb)

• Source of data
• -- Original-techn. papers.

• Mentioned in
• Catálogo LME 1963

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
