• Country
• Spain

• Manufacturer / Brand
• LME Laboratorio de Metrologia Electrónica; Barcelona

• Year
• 1963 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 169954

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 11

• Valves / Tubes
• ECL80 ECC81 ECL80 ECC81 ECF80 ECF82 ECC81 ECH81 ECC81 ECC81 EZ81 0A2

• Number of Transistors

• Semiconductors
• OA81 OA81

• Power type and voltage
• Alternating Current supply (AC) / 125; 220 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Generador de Vídeo M-231 - LME Laboratorio de Metrologia

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 310 x 210 x 180 mm / 12.2 x 8.3 x 7.1 inch

• Net weight (2.2 lb = 1 kg)
• 5 kg / 11 lb 0.2 oz (11.013 lb)

• Source of data
• -- Schematic

• Mentioned in
• Catálogo LME 1963

• Author
• Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.

• Other Models

• Here you find 104 models, 64 with images and 42 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from LME Laboratorio de Metrologia Electrónica; Barcelona
