Criterion IV
Lafayette Radio & TV Corp; New York (NY)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Lafayette Radio & TV Corp; New York (NY)
- Year
- 1968
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 239964
-
- alternative name: Wholesale Radio
By Courtesy Of EBAY User: amwbarn
By Courtesy Of EBAY User: amwbarn
By Courtesy Of EBAY User: amwbarn
By Courtesy Of EBAY User: amwbarn
catalog no 684 1968 page 2-3
- Number of Transistors
- 17
- Semiconductors
- Main principle
- Superhet with RF-stage
- Wave bands
- FM Broadcast Band Only
- Power type and voltage
- Alternating Current supply (AC) / 110-120 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 inch = 12.7 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Criterion IV - Lafayette Radio & TV Corp; New
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 14.5 x 8.25 x 9 inch / 368 x 210 x 229 mm
- Notes
-
Lafayette Table Top FM Radio Model Criterion IV.
Built in FM antenna.
- Price in first year of sale
- 69.95 USD
- Mentioned in
- Lafayette Radio Catalog (catalog no 684 1968 page 2-3)
- Author
- Model page created by Franz Scharner. See "Data change" for further contributors.
