- Country
- United States of America (USA)
- Manufacturer / Brand
- Lafayette Radio & TV Corp; New York (NY)
- Year
- 1970
- Category
- Citizen Band Equipment
- Radiomuseum.org ID
- 318359
-
- alternative name: Wholesale Radio
Hersteller-Doku
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 19
- Semiconductors
- Main principle
- Transceiver; ZF/IF 455 kHz
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios)
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Metal case
- from Radiomuseum.org
- Model: HB-525E - Lafayette Radio & TV Corp; New
- Shape
- Chassis only or for «building in»
- Notes
-
CB (Citizen Band) TX/RX. 23 channels. Sensitivity 0.5 µV.
Delta tuning and Noise Limiter.19 transistors, 10 diodes and 1 thermistor.
First price in Italy: 149950 (ITL).
- Price in first year of sale
- 149,950.00 ITL
- Mentioned in
- -- Original prospect or advert (CQ Elettronica gennaio 1970)
- Literature/Schematics (1)
- Photofact CB Radio Manual, SAMS (CB-43, December 1972.)
- Author
- Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
