Stereo-Vollverstärker LA-224T

Stereo-Vollverstärker LA-224T; Lafayette Radio & TV (ID = 692901) Ampl/Mixer
Stereo-Vollverstärker LA-224T; Lafayette Radio & TV (ID = 1110473) Ampl/Mixer Stereo-Vollverstärker LA-224T; Lafayette Radio & TV (ID = 1110467) Ampl/Mixer
Stereo-Vollverstärker LA-224T; Lafayette Radio & TV (ID = 1110470) Ampl/Mixer Stereo-Vollverstärker LA-224T; Lafayette Radio & TV (ID = 463046) Ampl/Mixer
Stereo-Vollverstärker LA-224T; Lafayette Radio & TV (ID = 1110466) Ampl/Mixer Stereo-Vollverstärker LA-224T; Lafayette Radio & TV (ID = 1110468) Ampl/Mixer
Stereo-Vollverstärker LA-224T; Lafayette Radio & TV (ID = 1110469) Ampl/Mixer Stereo-Vollverstärker LA-224T; Lafayette Radio & TV (ID = 1110471) Ampl/Mixer
Stereo-Vollverstärker LA-224T; Lafayette Radio & TV (ID = 1110472) Ampl/Mixer
Use red slider bar for more.
Stereo-Vollverstärker LA-224T; Lafayette Radio & TV (ID = 1110473) Ampl/Mixer
Lafayette Radio & TV: Stereo-Vollverstärker LA-224T [Ampl/Mixer] ID = 1110473 933x457
Select picture or schematic to display from thumbnails on the right and click for download.
For model Stereo-Vollverstärker LA-224T, Lafayette Radio & TV Corp; New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  Lafayette Radio & TV Corp; New York (NY)
alternative name

Wholesale Radio
Year: 1969 ? Category: Audio Amplifier or -mixer
Semiconductors (the count is only for transistors) 16:
Main principle Audio-Amplification
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out 30 W (unknown quality)
from Radiomuseum.org Model: Stereo-Vollverstärker LA-224T - Lafayette Radio & TV Corp; New
Material Metal case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 260 x 90 x 195 mm / 10.2 x 3.5 x 7.7 inch
Notes Musikleistung 2x15 Watt Stereo oder 1x30 Watt Mono, Frequenzbereich 20 bis 25000 Hz, 4 umschaltbare Eingänge: magn.TA, Kristall TA, Tuner, Tonband, Eingangsspannungen: 5 mV, 600 mV, Ausgänge: 2fach 8 und 16 Ohm umschaltbar, 2fach Tonband.
Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Price in first year of sale 269.00 DM
Mentioned in - - Manufacturers Literature (Rim-Katalog 1969)

Model page created by Karlheinz Fischer. See "Data change" for further contributors.
