XBS AM/FM Stereo Radio Cassette Recorder 6008
Larsen; (where?)
- Country
- Worldwide
- Manufacturer / Brand
- Larsen; (where?)
- Year
- 2000 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 316212
- Number of Transistors
- 4
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Line / Batteries (any type) / 220 or D: 6 x 1.5 Volt
- Loudspeaker
- 2 Loudspeakers / Ø 8.5 cm = 3.3 inch
- Power out
- 3 W (unknown quality)
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: XBS AM/FM Stereo Radio Cassette Recorder 6008 - Larsen; where?
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 580 x 140 x 140 mm / 22.8 x 5.5 x 5.5 inch
- Notes
-
Radio with double cassette stereo. FM stereo indicator. FM mode stereo or mono. Phono jack. Separate volume controls-left/right.
Cassette: "A" Auto stop cassette recorder. "B": High quality and high quality dubbing.
High and normal dubbing speed.
Function:Tape/Mic/Radio, therefore the single microphone is not for recording.
- Net weight (2.2 lb = 1 kg)
- 1.9 kg / 4 lb 3 oz (4.185 lb)
- Author
- Model page created by Pier Antonio Aluffi. See "Data change" for further contributors.
