Transistors 9T6

Transistors 9T6; Pathé-Marconi, Les (ID = 2218956) Radio Transistors 9T6; Pathé-Marconi, Les (ID = 2218955) Radio
Transistors 9T6; Pathé-Marconi, Les (ID = 2218960) Radio Transistors 9T6; Pathé-Marconi, Les (ID = 2218954) Radio
Transistors 9T6; Pathé-Marconi, Les (ID = 2218957) Radio Transistors 9T6; Pathé-Marconi, Les (ID = 2218958) Radio
Transistors 9T6; Pathé-Marconi, Les (ID = 2218959) Radio Transistors 9T6; Pathé-Marconi, Les (ID = 1784371) Radio
Transistors 9T6; Pathé-Marconi, Les (ID = 1354248) Radio Transistors 9T6; Pathé-Marconi, Les (ID = 1784370) Radio
Use red slider bar for more.
Transistors 9T6; Pathé-Marconi, Les (ID = 2218956) Radio
Pathé-Marconi, Les: Transistors 9T6 [Radio] ID = 2218956 1382x916
Select picture or schematic to display from thumbnails on the right and click for download.
For model Transistors 9T6, Pathé-Marconi, Les IME (I.M.E.), La Voix de son Maître; Paris

Country:  France
Manufacturer / Brand:  Pathé-Marconi, Les IME (I.M.E.), La Voix de son Maître; Paris
alternative name

La Voix de son Maître
Year: 1959 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6:
Main principle Superheterodyne (common); ZF/IF 480 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 2 x 4,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 0.25 W (unknown quality)
from Radiomuseum.org Model: Transistors 9T6 - Pathé-Marconi, Les IME I.M.E.,
Material Plastics (no bakelite or catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 220 x 135 x 80 mm / 8.7 x 5.3 x 3.1 inch
Notes

Different body color combinations known.

Net weight (2.2 lb = 1 kg) 1.5 kg / 3 lb 4.9 oz (3.304 lb)
Source of data - - Manufacturers Literature
Mentioned in Le grand livre de la TSF (N° fiche = 25014)

Model page created by a member from A. See "Data change" for further contributors.



All listed radios etc. from Pathé-Marconi, Les IME (I.M.E.), La Voix de son Maître; Paris
Here you find 176 models, 142 with images and 58 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
