Audio Generator LAG-120B

Audio Generator LAG-120B; Leader Electronics (ID = 2090291) Equipment

Audio Generator LAG-120B; Leader Electronics (ID = 2090279) Equipment

Audio Generator LAG-120B; Leader Electronics (ID = 2090280) Equipment

Audio Generator LAG-120B; Leader Electronics (ID = 2090281) Equipment

Audio Generator LAG-120B; Leader Electronics (ID = 2090283) Equipment

Audio Generator LAG-120B; Leader Electronics (ID = 2090284) Equipment

Audio Generator LAG-120B; Leader Electronics (ID = 2090285) Equipment

Audio Generator LAG-120B; Leader Electronics (ID = 2090286) Equipment

Audio Generator LAG-120B; Leader Electronics (ID = 2090287) Equipment

Audio Generator LAG-120B; Leader Electronics (ID = 2090288) Equipment
Use red slider bar for more.
Audio Generator LAG-120B; Leader Electronics (ID = 2090291) Equipment
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Japan
Manufacturer / Brand:  Leader Electronics Corp.; Yokohama
Year: 1986 Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) 10: 2SC372 2SC2240 2SA1016 2SC2362 2SC2911 µPA71A 1S1555 1S1588 W02M 1DZ61 RD10E AN7824 AN7924 CD4093
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 100; 120; 220; 240 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Audio Generator LAG-120B - Leader Electronics Corp.;
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 132 x 170 x 305 mm / 5.2 x 6.7 x 12 inch
Notes

Frequency range: 10 Hz to 1 MHz in five decade bands.
Output: sine wave over 3 Vrms into 600 ohms, square wave over 3 Vp-p into 600 ohms.

Semiconductors listed once per type. HD14093BP is a licence production of Hitachi CD4093.

Net weight (2.2 lb = 1 kg) 3 kg / 6 lb 9.7 oz (6.608 lb)
