Function Generator LFG-1300

Function Generator LFG-1300; Leader Electronics (ID = 1003372) Equipment

Function Generator LFG-1300; Leader Electronics (ID = 1003373) Equipment

Function Generator LFG-1300; Leader Electronics (ID = 1003374) Equipment

Function Generator LFG-1300; Leader Electronics (ID = 1003375) Equipment

Function Generator LFG-1300; Leader Electronics (ID = 1003376) Equipment

Function Generator LFG-1300; Leader Electronics (ID = 1003377) Equipment

Function Generator LFG-1300; Leader Electronics (ID = 1003378) Equipment

Function Generator LFG-1300; Leader Electronics (ID = 1003379) Equipment

Function Generator LFG-1300; Leader Electronics (ID = 1003380) Equipment

Function Generator LFG-1300; Leader Electronics (ID = 1003381) Equipment
Function Generator LFG-1300; Leader Electronics (ID = 390938) Equipment
Use red slider bar for more.
Function Generator LFG-1300; Leader Electronics (ID = 390938) Equipment
Leader Electronics: Function Generator LFG-1300 [Equipment] ID = 390938 933x575
Select picture or schematic to display from thumbnails on the right and click for download.
For model Function Generator LFG-1300, Leader Electronics Corp.; Yokohama

Country:  Japan
Manufacturer / Brand:  Leader Electronics Corp.; Yokohama
Year: 1988 ?? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: Function Generator LFG-1300 - Leader Electronics Corp.;
Material Metal case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 250 x 125 x 250 mm / 9.8 x 4.9 x 9.8 inch
Notes Sweep function generator 0,002 Hz to 2 MHz in eight dekade ranges. Linear and logarithmic sweep 20 ms to 5s, 10:1 to 1000:1, internal or external VCG. AM modulation 0-95 %. Output signals sine, triangle, square, puls, sawtooth, DC and TTL.
Net weight (2.2 lb = 1 kg) 4 kg / 8 lb 13 oz (8.811 lb)
Price in first year of sale 1'995.00 DM
Mentioned in RIM electronic 88

Model page created by Georg Richter. See "Data change" for further contributors.
