NTSC Pattern Generator LCG-396

NTSC Pattern Generator LCG-396; Leader Electronics (ID = 2034445) Equipment NTSC Pattern Generator LCG-396; Leader Electronics (ID = 2034446) Equipment
NTSC Pattern Generator LCG-396; Leader Electronics (ID = 2034447) Equipment
Use red slider bar for more.
NTSC Pattern Generator LCG-396; Leader Electronics (ID = 2034445) Equipment
Leader Electronics: NTSC Pattern Generator LCG-396 [Equipment] ID = 2034445 1400x1077
Select picture or schematic to display from thumbnails on the right and click for download.
For model NTSC Pattern Generator LCG-396, Leader Electronics Corp.; Yokohama

Country:  Japan
Manufacturer / Brand:  Leader Electronics Corp.; Yokohama
Year: 1980 ?? Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: NTSC Pattern Generator LCG-396 - Leader Electronics Corp.;
Material Metal case
Shape Tablemodel, with any shape - general.
Notes

The Leader LCG-396 is a NTSC-M pattern generator designed to produce standard 75% color bars as well as other test signals for use in alignment and troubleshooting of video monitors, receivers and video tape recorders.
