Leningrad {Ленинград} 002

Leningrad NOVATOR Works

  • Year
  • 1975
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 99359

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 37
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast, Long Wave, more than 2 x SW plus FM or UHF.
  • Power type and voltage
  • Line / Batteries (any type) / 127/220/6 x 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Power out
  • 1 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Leningrad {Ленинград} 002 - Leningrad NOVATOR Works
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 390 x 394 x 164 mm / 15.4 x 15.5 x 6.5 inch
  • Notes
  • Huge portable high class radio (most in SU as radio with battery).
    Coverage LW, 2 MW bands, 5 SW bands and FM. Three FM frequency preset buttons.
  • Net weight (2.2 lb = 1 kg)
  • 9 kg / 19 lb 13.2 oz (19.824 lb)
  • Price in first year of sale
  • 200.00 RUR
  • Mentioned in
  • - - Data from my own collection
  • Author
  • Model page created by Zenonas Langaitis. See "Data change" for further contributors.
