• Year
  • 1964 ?
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 213380

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 5
  • Semiconductors
  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / 2x 9 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • from Radiomuseum.org
  • Model: R.C. Oscillator TG150 - Levell Electronics Ltd ;
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • Levell Electronics R.C. oscillator model TG150. Sine wave output only. No output meter.
  • Source of data
  • -- Original-techn. papers.
