• Country
• France

• Manufacturer / Brand
• LGM (L.G.M.), Le Guyader Morlaix, Éts. Elgem; Morlaix

• Year
• 1935

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 269045

• Number of Tubes
• 6

• Valves / Tubes

• Main principle
• Superhet with RF-stage; 3 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage and/or dry batteries / 2 & ? Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: B12 - LGM L.G.M., Le Guyader Morlaix

• Shape
• Tablemodel, Box - most often with Lid (NOT slant panel).

• Dimensions (WHD)
• 600 x 340 x 300 mm / 23.6 x 13.4 x 11.8 inch

• Notes

• Récepteur à cadre orientable incorporé.

  Étage de sortie en push-pull.



• Mentioned in
• L'Éclaireur du Finistère, 07.12.1935, p.7

• Literature/Schematics (1)
• Le grand livre de la TSF (Doctsf Ref 6527)
